Headstock/valve accessories:
Features: |
| 1). ductile iron GGG500/7 |
| 2). fusion bonded epoxy coating |
| 3). BS5163,BS5150,DIN3352 F4/F5, AWWA |
Standard reference: |
| 1).Design and manufacuture standard: MSS SP-81,JB/T8691 etc |
| 2).Face to face dimention standard:MSS SP-81,GB/T15188.2 etc |
| 3).Flange connecting standard: ANSI B 16.5, JB/T79,DIN 2532,JIS B2212, BS4504 ect |
| 4).Test and inspection standard:MSS SP-81,JB/T8691 etc |
Material for main parts: |
| Body: CF8/CF8M/CF3/CF3M/A105/LF2/F11 and so on. |
| Knife: SS304 / 304L/ SS316/ 316L /WCB / LCB / WC9 and so on |
| Stem: 304/ 316/ Cr13% and so on |
| Seat: Rubber/ Teflon /PTFE/ Hard Alloy/Cr13% etc |
| Packing: PTFE, Strenged Graphite etc |
