  • Air Valve
  • Air Valve
  • Air Valve
  • Air Valve
  • Air Valve
  • Air Valve
  • Air Valve
  • Air Valve

Specification:

Material for valve body :cast iron or ductile iron
Working pressure:PN1.0--2.5MPa
Standard:DIN/BS/AWWA
Size: 50-400mm/2" - 16"
Wedge : D/I , core fully vulcanized with NBR or EPDM rubber
Wedge Nut : Brass
Stem : Stainless steel , BS970 431S29 or DIN17440x20Cr13
Gasket : NBR
Bonnet : GGG500-7
O ring : NBR
Washer : Carbon steel or Stainless steel
Pressure grade: PN10, PN16
Coating:Fusion-bonded epoxy 200-250 microns inside and out side or Coating as per customers' requirement
Package : carton for each item , wooden boxes outside
